Barrel Pump Unit
●Safe and leak-free, efficient and reliable
●High-pressure internal circulation prevents liquid from vaporizing
●Automatic oil return improves system efficiency
●It can supply liquid over a long distance, and the efficiency of full liquid supply is about 30% higher than that of direct expansion liquid supply.
●Expand the operating range and upgrade the motor temperature to NTC configuration
Parameter
Design Pressure:1.4MPa; Pump inlet size:40mm; Pump outlet size:32mm; IP Rate: IP55.
| Unit Model | Volume | Rate of flow | Weight | L*W*H |
SWZBF1.0 | 1000L | 3m³ | 590kg | 4020*1800*2800mm |
SWZBF2.0 | 2000L | 6m³ | 940kg | 4020*1800*2800mm |
SWZBF3.0 | 3000L | 10m³ | 1200kg | 4020*2000*3000mm |
SWZBF4.0 | 4000L | 15m³ | 1700kg | 4020*2100*3200mm |
SWZBF5.0 | 5000L | 18m³ | 2000kg | 4020*2300*3400mm |
Application Case
2022 Winter Olympics Venue (National Speed Skating Stadium)
Refrigeration host:
The system configuration uses 6 CO2 transcritical parallel compressor units, each unit uses 6 compressors to meet the cooling capacity requirements of the project's transcritical ice pouring conditions.
Gas cooler: The system configuration uses 6 CO2 cooling gas coolers to meet the cooling needs of all equipment in the project;
The barrel pump unit: The system uses four 14m³ CO2 barrel pump units independently developed by ARKREF and is equipped with a dedicated low-temperature circulation pump for CO2 to meet the system cooling capacity and CO2 storage requirements.
